Cord Stopper

Definition and Overview

A cord stopper is a component that clamps a cord threaded through a hole with a spring or retaining section to fix its extended position. It allows one-handed adjustment of drawcord length and opening size, and can be loosened again as needed.

In general, many designs use a button-shaped body that is pressed to release the lock, then the cord is moved before the hand is released. Round cord is the most common, but there are also shapes that support flat cord, tape, and multiple cords.

Materials and Structure

The body is often made of lightweight, rust-resistant resin such as nylon, ABS resin, or polyacetal. Metal types are easier to achieve in texture and strength, but require consideration of weight, corrosion, and discoloration due to surface treatment.

The basic structure consists of the body, a movable part that holds the cord, and a spring that provides restoring force. In spring-loaded types, the combination of push-in amount, cord surface friction, and hole shape affects holding force and feel of operation.

• Resin type: lightweight and easy to use in apparel, with color variations easy to create.
• Metal type: easy to give a refined appearance, but product weight and wet environments should be checked.
• Spring-loaded type: easy to operate, but because it contains a spring, confirmation of needle detector conditions is necessary.

How to Express Size

When selecting, check not only the outer dimensions of the body but also the inner dimensions of the hole through which the cord passes and the compatible cord thickness. For round cord, match the hole diameter with the actual measured cord diameter; for flat cord and tape, match both the inner dimensions of the opening and the tape width and thickness to be threaded.

If the cord is too thin, it may slip and not hold; if it is too thick, it may be difficult to thread or may become harder to operate. Because brushed cord, wax cord, and elastic cord differ in friction and thickness, it is important to confirm with prototypes using the actual combination.

Main Applications

In outerwear and sportswear, it is used to adjust drawcords at the hood opening, hem, waist, and cuffs. The main purposes are to improve fit to the body, help wind resistance, and change the silhouette.

In bags, pouches, and drawstring bags, it is used to tighten the opening and prevent contents from falling out. For kids' products and work use, in addition to operability, safety is considered including snagging, detachment, and cord-end finishing.

How to Choose and Precautions

Select based on the type of cord used, thickness, number of cords, and required holding force. At load-bearing points or points that are opened and closed frequently, check in the product specifications whether the cord will not pull out under tension and whether the lock continues to function after repeated operation.

Metal parts may rust or discolor depending on the usage environment, such as sweat, moisture, washing, and seawater. For resin parts as well, consider effects on appearance and strength from chemicals, heat, ultraviolet light, and low temperatures, and evaluate under conditions including washing and secondary processing.

For products that undergo needle detection, a cord stopper with a metal spring built in may react to the detector. Confirm before production whether needle detector compatibility is necessary, the detector settings, and consistency with foreign-object contamination control. A cord end is a part that finishes the end of the cord, and its role differs from that of a cord stopper, which fixes and adjusts the position of the cord.
